Product Description
A rotary inspection table provides a continuously rotating surface that presents product to operators positioned around it. Operators can visually inspect and manually sort items as the product moves; the table alone does not perform automatic grading or identify defects.
Suitability depends on product dimensions and weight, feed rate, required inspection time, number of operators, available space, and the planned infeed/outfeed arrangement. Share these details to review the table size and configured drive arrangement.
Product Details
- Capacity – 2 Meter.
- S.S. Body.
- 2 HP 1440 RPM Motor with 3 Inch Gearbox.
- With Electronic Control Panel
How a rotary table works
A rotary table uses a rotating surface to present items to operators for manual visual inspection or sorting. Rotation alone does not identify defects or automatically grade items.
- Items are placed on the table through the planned feed arrangement.
- The motor and gearbox rotate the surface at the configured speed.
- Rotation moves items around the work surface so operators can inspect them.
- Operators visually inspect and manually remove or sort items as required by the agreed task.
- Infeed, outfeed and collection arrangements are confirmed to suit the surrounding line.
Main components and construction
- Rotating table surface: carries and presents items to the operators.
- Motor and gearbox: provide the drive for table rotation; speed range and control method depend on the supplied configuration.
- Electronic control panel: provides the operating controls included with the machine.
- Body: the current product details list an S.S. body. Confirm grade, finish and product-contact suitability for the application in the approved specification.
What to confirm for your line
Review product size and weight, feed rate, table working load and dimensions, inspection time, operator count, working height, floor space, cleaning needs and the planned infeed/outfeed. Confirm table dimensions, rated working load and drive/control arrangements in the approved drawing or quotation before matching the table to an existing line.
Frequently Asked Questions
Does it grade products automatically?
No. The table presents and distributes items for manual inspection. Automatic identification or grading would require a separate system if needed.
What sets table size and speed?
Feed rate, item size, operator count, inspection time, working load and available floor space must be considered together.
What do you need to assess a table?
Share product dimensions and weight, feed rate, inspection task, operator count, working-space constraints, and how material enters and leaves the table.
Discuss your rotary-table requirement: Share the product dimensions and feed rate, inspection or sorting task, number of operators, and available floor space. Clarify whether you need a manual inspection table or a separate automatic grading system. Contact Thermocare, call +91 79916 56592 or +91 96705 15151, or WhatsApp either number: +91 79916 56592 / +91 96705 15151.
